3800929 Lower Gasket Kit Cummins Engine 6C, 6CT, 6CTA, ISC, QSC, QSL, ISL

Lower Gasket kit Engine Cummins Engine 6C – Engine 6CT – Engine 6CTA

Name: Lower Gasket kit Engine Cummins Engine 6C - Engine 6CT - Engine 6CTA
SKU: PDPM3800929
Price: 352.85 USD
Availability: InStock

Lower Gasket Set Engine Cummins Engine 6C 8.3 – Engine 6CT 8.3 – 6CTA 8.3

This kit is designed for the lower part of the engine and includes gaskets, O-rings, seals, and oil seals used during engine overhaul or rebuild. It is used to restore the sealing integrity of the lower engine components, primarily preventing leaks of oil, coolant, and other fluids, as well as ensuring proper sealing of the components during an overhaul.

Motors with verified compatibility: 6C 8.3, 6CT 8.3, 6CTA 8.3, ISC 8.3, QSCC 8.3, ISL 8.9, QSL 8.9

Final compatibility must always be verified using the ESN and CPL, because not all configurations within the same engine family necessarily use the same gasket set.

$352.85

In Stock

SKU: PDPM3800929 Categories: 6C 8.3, 6CT 8.3, 6CTA 8.3, C Series, Cummins, Cylinder Head, Cylinder Head, Cylinder Head, Gaskets, Gaskets, Gaskets Tag: Motor

Description
Additional information

Description

Part Number Component Qty: 3040817 O-Ring 2, 3678912 O-Ring 4, 3902425 Sealing Washer 1, 3903475 Rectangular Sealing Ring 1, 3907177 Sealing Ring 6, 3913032 Water Outlet Gasket 1, 3918174 Oil Cooler Core Gasket 1, 3926048 O-Ring 1, 3929011 Oil Cooler Cover Gasket 1, 3939258 Fuel Pump Gasket 1, 3914302 Oil Suction Gasket 1, 3940245 Compressor Mounting Gasket 1, 3944293 Gear Housing Gasket 1, 3945435 Piston Cooling Nozzle 6, 4025270 Front Crankshaft Seal Kit 1, 3909410 / 5259499 Rear Crankshaft Seal 1 each.

Additional information

Weight	3.700 lbs
Dimensions	38 × 17 × 2 in

Engine Kit Part No.	Description	Qty	Part Comment
FP-3802811	Cylinder Kit Complete	6	Piston FP–3929161 & Liner Kit FP–3802407
FP-3945917	Main Bearing Set – STD	1
FP-3901430	Rod Bearing Half Upper/Lower – STD	12
FP-4025271	Head Gasket Set	1
FP-3800558	Conversion Gasket Set	1

FP-3802811	Cylinder Kit Complete	6	Piston FP–3929161 & Liner Kit FP–3802407
FP-3945917	Main Bearing Set – STD	1
FP-3901430	Rod Bearing Half Upper/Lower – STD	12
FP-4025271S	In-Frame Gasket Set	1

Engine Kit Part No.	Description	Qty	Part Comment
FP-3802388	Cylinder Kit Complete	6	Piston FP–3917707 & Liner Kit FP–3802370
FP-3945917	Main Bearing Set – STD	1
FP-3901430	Rod Bearing Half Upper/Lower – STD	12
FP-4025271S	In-Frame Gasket Set	1

Engine Kit Part No.	Description	Qty	Part Comment
FP-3802388	Cylinder Kit Complete	6	Piston FP–3917707 & Liner Kit FP–3802370
FP-3945917	Main Bearing Set – STD	1
FP-3901430	Rod Bearing Half Upper/Lower – STD	12
FP-4025271	Head Gasket Set	1
FP-3800558	Conversion Gasket Set	1
